1785 Manifold 2-1/2"
US Gauge

1785 Manifold 2-1/2"

SKU:
16912
Availability:
Usually ships within 4 Weeks
Size:
2-1/2"
Model:
1785
Product Type:
Refrigeration
Accuracy:
±3-2-3% of span (Grade B), applies to non-retard portion
Connection Size:
1/8-27 NPT LM, brass
Case:
ABS (P-1785 – red; CR-1785 – blue)
Bourdon Tube:
Phosphor bronze
Dial:
Steel, white background with black markings; refrigerant temperature scales in red
Range of measurement:
PSI
Designed for use with various types of refrigerants, Model 1785-HVAC/R manifold pressure gauges are available in several ranges including R-12, R-22, R-502, R-134A, and R-410A. The gauges can be permanently mounted in cooling systems, or used on portable manifolds. The Type CR-1780 is supplied with a 350 psi retard scale to accommodate accidental over-pressure. All gauges make use of a unique, removable, one-piece threaded plastic ring and window to allow quick, easy access to the pointer’s internal adjusting screw. These accurate, sturdy refrigerant gauges are available in English, dual scale, and metric-only ranges.
This product comes with a 1 year Warranty
!
